1. Introduction to Certification

NCC is the abbreviation of The National Communications Commission of Taiwan, which mainly controls the communication and information equipment circulated and used in the Taiwan market:
1. LPE: Low Power Equipment, that is, low-power equipment (for example: Bluetooth, WIFI equipment);
2. TTE: Telecommunications Terminal Equipment, that is, communication terminal equipment (such as mobile phones and tablet devices).

2. Certification mark

3. Product range

1. Low-power RF motors with operating frequency from 9kHz to 300GHz, such as: wireless network (WLAN) products (including IEEE 802.11a/b/g), UNII, Bluetooth products, RFID, ZigBee, wireless keyboards, wireless mice, Wireless earphones and microphones, radio walkie-talkies, radio remote control toys, various radio remote controls, various wireless anti-theft devices, etc. the
2. Public switched telephone network equipment (PSTN) products, such as wired telephones (including VOIP network telephones), automatic alarm equipment, telephone answering machines, fax machines, remote control devices, wired telephone wireless master and auxiliary machines, key telephone systems , Data equipment (including ADSL equipment), incoming call display terminal equipment, 2.4GHz radio frequency telecommunications terminal equipment, etc.
3. Land mobile communication network equipment (PLMN) products, such as wireless broadband access mobile station equipment (WiMAX mobile terminal equipment), GSM 900/DCS 1800 mobile phone and terminal equipment (2G mobile phone), third-generation mobile communication terminal equipment (3G mobile phone), etc.

4. Sample requirements

1. Two RF fixed-frequency prototypes and one ordinary prototype.
2. The fixed-frequency prototype is aimed at multi-channel working products. If it is a single-channel prototype, please provide a continuous transmission prototype.

5. Certification Standards

6. Test items

1. RF test;

2. Occupied bandwidth test;

3. Output power and power density;

4. In-band spurious test;

5. Radiation spurious test, etc.

7. Required information

1. Instruction Manual
2. Bill of Materials
3. PCB wiring diagram
4. Block diagram
5. PCB bit number map
6. Circuit schematic diagram
7. Wireless module specifications, wireless module antenna specifications
8. Fixed frequency operation
9. Product labeling
10. The manufacturer's certificate is required in other places, and the local certificate holder needs to provide a radio frequency use certificate

8. Certification process

1. Receive the sample for pre-test, and prepare the above materials during the test.
2. After the test is completed, arrange to send samples to Taiwan for testing.
3. Afterwards, the report and certificate will be issued by Taiwan.

9. Certification cycle and validity period

Validity period of the certificate: long-term validity, the NCC certification period is about 5-6 weeks.

10. Factory inspection

No factory inspection.

11. Specifications for the use of logos

1. NCC logo: NCC's LOGO must be larger than 15mm.
2. Label: must be attached to the product itself, if the product is too small, it can be printed on the small package.
CCXXxxYYyyyZzW
XX:CertificateBody Issuing agency
xx:YearYear
YY: LP (LowerPowerDevice) low power consumption device
yyy:SerialNumber serial number
Z:SeriesNumber number
z: Mode model

China Taiwan NCC certification

· Detection content: wireless · Applicable products: wireless communication products · Whether mandatory: Yes ·Factory Inspection: None ·Local agent: no ·Plug type: US standard ·Voltage requirement: 110V ·Application method: direct application ·Certificate holder: ·Certificate validity period: long-term ·Official website: ·Certificate query website: ·Other supplements:
